| Unit Model | Power | Diesel Engine Brands | Diesel Engine Model | National Standard | Displacement（L） | Bore*Stroke（mm） | Particulars | |
| Prime Power(KVA) | Standby Power(KVA) | |||||||
| HNCMS20D | 25 | 30 | Cummins | 4B3.9-G2 | T2 | 3.9 | 102*120 | View Details |
| HNCMS25D | 30 | 34 | Cummins | 4B3.9-G12 | T2 | 3.9 | 102*120 | View Details |
| HNCMS30D | 37 | 44 | Cummins | 4BT3.9-G2 | T2 | 3.9 | 102*120 | View Details |
| HNCMS50D | 62 | 70 | Cummins | 4BTA3.9-G2 | T2 | 3.9 | 102*120 | View Details |
| HNCMS64D | 80 | 90 | Cummins | 4BTA3.9-G11 | T2 | 3.9 | 102*120 | View Details |
| HNCMS75D | 93 | 105 | Cummins | 4BTA3.9-G13 | T2 | 3.9 | 102*120 | View Details |
| HNCMS90D | 112 | 125 | Cummins | 6BTA5.9-G2 | T2 | 5.9 | 102*120 | View Details |
| HNCMS100D | 125 | 145 | Cummins | 6BTAA5.9-G2 | T2 | 5.9 | 102*120 | View Details |
| HNCMS120D | 150 | 165 | Cummins | 6BTAA5.9-G12 | T2 | 5.9 | 102*120 | View Details |
| HNCMS145D | 180 | 200 | Cummins | 6CTA8.3-G2 | T2 | 8.3 | 114*135 | View Details |
| HNCMS200D | 250 | 264 | Cummins | 6LTAA8.9-G2 | T2 | 8.9 | 114*145 | View Details |
| HNCMS250D | 312 | 350 | Cummins | 6LTAA9.5-G1 | T2 | 9.5 | 116*148 | View Details |
| HNCMS300D | 375 | 425 | Cummins | 6ZTAA13-G3 | T2 | 13 | 130*163 | View Details |
| HNCMS350D | 438 | 475 | Cummins | 6ZTAA13-G4 | T2 | 13 | 130*163 | View Details |
| HNCMS400D | 500 | 550 | Cummins | QSZ13-G10 | T3 | 13 | 130*163 | View Details |
 |
loading
| Availability: | |
|---|---|
| Quantity: | |
HN18D
HAONENG Power
Diesel Generator Set-Basic Parameters
Model: HN18D
Rated power: 22(KVA)
Output current: 32（A）
Weight: 920（KG）
Silent type size: 2100*900*1200
Output voltage: 400/230 (V)
Diesel Engine-Basic Parameters
Model: HN490D
Rated power: 27(KVA)
Emission standard: T2
Manufacturer: HAONENG
Bore: 90（mm）
Stroke: 100（mm）
Speed control mode: electronic speed control
Displacement: 2.544（L）
Fuel consumption rate: 200 (g/Kw.h)
Oil consumption rate: 0.3 (g/Kw.h)
Cooling method: Closed water circulation forced air-cooled
Speed: 1500 (RPM)
Thermostat adjustment temperature range: 82-93 (°C)
Exhaust temperature: 405/410 (°C)
Allowable back pressure: 10 (KPa)
Intake air resistance: 2.5 (KPa)
Fuel specification and grade: China 0# (light diesel oil)
Fuel consumption: ≤250（g/Kw.h）
Cylinder arrangement: L-type
Starting method: electric start
Controller-Basic Parameters
Brand: SmartGen/DSE
Display mode: LCD
Language type: support for the world's eight languages
Automatic function: automatic start, automatic stop
Motors - Basic Parameters
Model: HN-184E
Rated power: 22（KVA)
Standby power: 25（KVA)
Brand: HAONENG (standard)
Motor type: brushless three-phase AC synchronous generator
Voltage Regulation: AVR (Automatic Voltage Regulation)
Temperature rise: H°C
Overcurrent: 3～5le≥5S
Overload capacity: 3～5le≥5S
Short-circuit current: 3 times 2 seconds
Short-circuit capability: 3 times 2 seconds
Power factor: 0.8
Insulation/protection grade: H class/IP23
Wiring: three-phase four-wire, Y-type connection
Rated voltage: 400/230(V)
Winding material: pure copper
Cooling method: self-cooling
Excitation method: self-excitation
Telephone interference factor: THF<2, TIF<50
Attachment
Housings：21mm Plate Thickness
Sump：4mm Thick
Surface Treatment Process：Shot Peening Plus Plastic Spraying
Connecting chassis material: bending steel plate
Chassis strength: passed 500KG torsion test
Unit steel common base (including: unit composite vibration damping rubber mat)
Cooling water tank capacity: 8 Hours As Standard
Cooling water tank heat sink spacing: 0.80CM
Fuel tank material: 2MM high-quality cold-rolled steel plate
Silencer box: honeycomb double-layer industrial silencer
Vibration damping pads: bowl type or square type rubber vibration damping pads
Battery: Varta
