| Unit Model | Power | Diesel Engine Brands | Diesel Engine Model | National Standard | Displacement（L） | Bore*Stroke（mm） | Particulars | |
| Prime Power(KVA) | Standby Power(KVA) | |||||||
| HNPJS16D | 20 | 22 | Perkins | 404D-22G | T3 | 2.2 | 84*100 | View Details |
| HNPJS24D | 30 | 32 | Perkins | 1103A-33G | T3 | 3.3 | 105*127 | View Details |
| HNPJS36D | 45 | 50 | Perkins | 1103A-33TG1 | T3 | 3.3 | 105*127 | View Details |
| HNPJS48D | 60 | 66 | Perkins | 1103A-33TG2 | T3 | 3.3 | 105*127 | View Details |
| HNPJS64D | 80 | 87 | Perkins | 1104A-44TG2 | T3 | 4.41 | 105*127 | View Details |
| HNPJS80D | 100 | 112 | Perkins | 1104C-44TAG2 | T3 | 4.41 | 105*127 | View Details |
| HNPJS108D | 135 | 150 | Perkins | 1106A-70TG1 | T3 | 7.01 | 105*135 | View Details |
| HNPJS120D | 150 | 165 | Perkins | 1106A-70TAG2 | T3 | 7.01 | 105*135 | View Details |
| HNPJS144D | 180 | 200 | Perkins | 1106A-70TAG3 | T3 | 7.01 | 105*135 | View Details |
| HNPJS160D | 200 | 220 | Perkins | 1106A-70TAG4 | T3 | 7.01 | 105*135 | View Details |
| HNPJS200D | 250 | 275 | Perkins | 1206A-E70TTAG3 | T3 | 7.01 | 105*135 | View Details |
| HNPJS245D | 300 | 338 | Perkins | 1706A-E93TAG1 | T3 | 9.3 | 115*149 | View Details |
| HNPJS280D | 350 | 400 | Perkins | 2206C-E13TAG2 | T3 | 12.5 | 130*157 | View Details |
| HNPJS320D | 400 | 450 | Perkins | 2206C-E13TAG3 | T3 | 12.5 | 130*157 | View Details |
| HNPJS364D | 455 | 500 | Perkins | 2506C-E15TAG1 | T3 | 15.2 | 137*171 | View Details |
| HNPJS400D | 500 | 550 | Perkins | 2506C-E15TAG2 | T3 | 15.2 | 137*171 | View Details |
 |
loading
| Availability: | |
|---|---|
| Quantity: | |
HN18D
HAONENG Power
Diesel Generator Set-Basic Parameters
Model: HN18D
Rated power: 22(KVA)
Output current: 32（A）
Weight: 920（KG）
Silent type size: 2100*900*1200
Output voltage: 400/230 (V)
Diesel Engine-Basic Parameters
Model: HN490D
Rated power: 27(KVA)
Emission standard: T2
Manufacturer: HAONENG
Bore: 90（mm）
Stroke: 100（mm）
Speed control mode: electronic speed control
Displacement: 2.544（L）
Fuel consumption rate: 200 (g/Kw.h)
Oil consumption rate: 0.3 (g/Kw.h)
Cooling method: Closed water circulation forced air-cooled
Speed: 1500 (RPM)
Thermostat adjustment temperature range: 82-93 (°C)
Exhaust temperature: 405/410 (°C)
Allowable back pressure: 10 (KPa)
Intake air resistance: 2.5 (KPa)
Fuel specification and grade: China 0# (light diesel oil)
Fuel consumption: ≤250（g/Kw.h）
Cylinder arrangement: L-type
Starting method: electric start
Controller-Basic Parameters
Brand: SmartGen/DSE
Display mode: LCD
Language type: support for the world's eight languages
Automatic function: automatic start, automatic stop
Motors - Basic Parameters
Model: HN-184E
Rated power: 22（KVA)
Standby power: 25（KVA)
Brand: HAONENG (standard)
Motor type: brushless three-phase AC synchronous generator
Voltage Regulation: AVR (Automatic Voltage Regulation)
Temperature rise: H°C
Overcurrent: 3～5le≥5S
Overload capacity: 3～5le≥5S
Short-circuit current: 3 times 2 seconds
Short-circuit capability: 3 times 2 seconds
Power factor: 0.8
Insulation/protection grade: H class/IP23
Wiring: three-phase four-wire, Y-type connection
Rated voltage: 400/230(V)
Winding material: pure copper
Cooling method: self-cooling
Excitation method: self-excitation
Telephone interference factor: THF<2, TIF<50
Attachment
Housings：21mm Plate Thickness
Sump：4mm Thick
Surface Treatment Process：Shot Peening Plus Plastic Spraying
Connecting chassis material: bending steel plate
Chassis strength: passed 500KG torsion test
Unit steel common base (including: unit composite vibration damping rubber mat)
Cooling water tank capacity: 8 Hours As Standard
Cooling water tank heat sink spacing: 0.80CM
Fuel tank material: 2MM high-quality cold-rolled steel plate
Silencer box: honeycomb double-layer industrial silencer
Vibration damping pads: bowl type or square type rubber vibration damping pads
Battery: Varta
