| Unit Model | Power | Diesel Engine Brands | Diesel Engine Model | National Standard | Displacement（L） | Bore*Stroke（mm） | Particulars | |
| Prime Power(KVA) | Standby Power(KVA) | |||||||
| HNWEW68D | 85 | 93 | VOLVO | TAD530GE | T2 | 4.76 | 108*130 | View Details |
| HNWEW80D | 100 | 110 | VOLVO | TAD531GE | T2 | 4.76 | 108*130 | View Details |
| HNWEW100D | 125 | 137 | VOLVO | TAD532GE | T2 | 4.76 | 108*130 | View Details |
| HNWEW120D | 150 | 165 | VOLVO | TAD731GE | T2 | 7.15 | 108*130 | View Details |
| HNWEW144D | 180 | 200 | VOLVO | TAD732GE | T2 | 7.15 | 108*130 | View Details |
| HNWEW200D | 250 | 275 | VOLVO | TAD734GE | T2 | 7.15 | 108*130 | View Details |
| HNWEW250D | 312 | 343 | VOLVO | TAD1341GE | T2 | 12.78 | 131*158 | View Details |
| HNWEW300D | 375 | 413 | VOLVO | TAD1343GE | T2 | 12.78 | 131*158 | View Details |
| HNWEW360D | 450 | 500 | VOLVO | TAD1345GE | T2 | 12.78 | 131*158 | View Details |
| HNWEW400D | 500 | 550 | VOLVO | TAD1641GE | T2 | 16.12 | 144*165 | View Details |
| HNWEW450D | 562 | 618 | VOLVO | TAD1642GE | T2 | 16.12 | 144*165 | View Details |
| HNWEW500D | 625 | 700 | VOLVO | TWD1644GE | T3 | 16.12 | 144*165 | View Details |
| HNWEW560D | 700 | 770 | VOLVO | TWD1645GE | T3 | 16.12 | 144*165 | View Details |
 |
loading
| Availability: | |
|---|---|
| Quantity: | |
HN18D
HAONENG Power
Diesel Generator Set-Basic Parameters
Model: HN18D
Rated power: 22(KVA)
Output current: 32（A）
Weight: 920（KG）
Silent type size: 2100*900*1200
Output voltage: 400/230 (V)
Diesel Engine-Basic Parameters
Model: HN490D
Rated power: 27(KVA)
Emission standard: T2
Manufacturer: HAONENG
Bore: 90（mm）
Stroke: 100（mm）
Speed control mode: electronic speed control
Displacement: 2.544（L）
Fuel consumption rate: 200 (g/Kw.h)
Oil consumption rate: 0.3 (g/Kw.h)
Cooling method: Closed water circulation forced air-cooled
Speed: 1500 (RPM)
Thermostat adjustment temperature range: 82-93 (°C)
Exhaust temperature: 405/410 (°C)
Allowable back pressure: 10 (KPa)
Intake air resistance: 2.5 (KPa)
Fuel specification and grade: China 0# (light diesel oil)
Fuel consumption: ≤250（g/Kw.h）
Cylinder arrangement: L-type
Starting method: electric start
Controller-Basic Parameters
Brand: SmartGen/DSE
Display mode: LCD
Language type: support for the world's eight languages
Automatic function: automatic start, automatic stop
Motors - Basic Parameters
Model: HN-184E
Rated power: 22（KVA)
Standby power: 25（KVA)
Brand: HAONENG (standard)
Motor type: brushless three-phase AC synchronous generator
Voltage Regulation: AVR (Automatic Voltage Regulation)
Temperature rise: H°C
Overcurrent: 3～5le≥5S
Overload capacity: 3～5le≥5S
Short-circuit current: 3 times 2 seconds
Short-circuit capability: 3 times 2 seconds
Power factor: 0.8
Insulation/protection grade: H class/IP23
Wiring: three-phase four-wire, Y-type connection
Rated voltage: 400/230(V)
Winding material: pure copper
Cooling method: self-cooling
Excitation method: self-excitation
Telephone interference factor: THF<2, TIF<50
Attachment
Housings：21mm Plate Thickness
Sump：4mm Thick
Surface Treatment Process：Shot Peening Plus Plastic Spraying
Connecting chassis material: bending steel plate
Chassis strength: passed 500KG torsion test
Unit steel common base (including: unit composite vibration damping rubber mat)
Cooling water tank capacity: 8 Hours As Standard
Cooling water tank heat sink spacing: 0.80CM
Fuel tank material: 2MM high-quality cold-rolled steel plate
Silencer box: honeycomb double-layer industrial silencer
Vibration damping pads: bowl type or square type rubber vibration damping pads
Battery: Varta
