| Unit Model | Power | Diesel Engine Brands | Diesel Engine Model | National Standard | Displacement（L） | Bore*Stroke（mm） | Particulars | |
| Prime Power(KVA) | Standby Power(KVA) | |||||||
| HNWC16D | 20 | 22 | WEICHAI | WP2.3D25E200 | T2 | 2.289 | 89*92 | View Details |
| HNWC24D | 30 | 32 | WEICHAI | WP2.3D33E200 | T2 | 2.289 | 89*92 | View Details |
| HNWC30D | 37 | 41 | WEICHAI | WP2.3D40E200 | T2 | 2.289 | 89*92 | View Details |
| HNWC36D | 50 | 55 | WEICHAI | WP2.3D48E200 | T2 | 2.289 | 89*92 | View Details |
| HNWC50D | 62 | 68 | WEICHAI | WP4.1D66E200 | T2 | 4.087 | 105*118 | View Details |
| HNWC64D | 80 | 87 | WEICHAI | WP4.1D80E200 | T2 | 4.087 | 105*118 | View Details |
| HNWC80D | 112 | 125 | WEICHAI | WP4.1D113E200 | T2 | 4.087 | 105*118 | View Details |
| HNWC100D | 125 | 137 | WEICHAI | WP6D132E200 | T2 | 6.75 | 105*130 | View Details |
| HNWC120D | 150 | 165 | WEICHAI | WP6D152E200 | T2 | 6.75 | 105*135 | View Details |
| HNWC160D | 187 | 220 | WEICHAI | WP10D200E200 | T2 | 9.726 | 126*130 | View Details |
| HNWC180D | 225 | 250 | WEICHAI | WP10D238E200 | T2 | 9.726 | 126*130 | View Details |
| HNWC200D | 250 | 275 | WEICHAI | WP10D264E200 | T2 | 9.726 | 126*130 | View Details |
| HNWC250D | 312 | 343 | WEICHAI | WP10D320E200 | T2 | 9.726 | 126*130 | View Details |
| HNWC300D | 375 | 412 | WEICHAI | WP12D353E200 | T2 | 11.59 | 126*155 | View Details |
| HNWC350D | 437 | 500 | WEICHAI | WP13D440E310 | T3 | 12.54 | 127*165 | View Details |
| HNWC400D | 500 | 550 | WEICHAI | WP13D490E310 | T3 | 12.54 | 127*165 | View Details |
| HNWC450D | 562 | 625 | WEICHAI | 6M33D572E200 | T2 | 19.6 | 150*185 | View Details |
| HNWC500D | 625 | 687 | WEICHAI | 6M33D633E200 | T2 | 19.6 | 150*185 | View Details |
| HNWC600D | 750 | 825 | WEICHAI | 6M33D725E310 | T3 | 19.6 | 150*185 | View Details |
| HNWC640D | 800 | 900 | WEICHAI | 8M33D800E200 | T2 | 26.14 | 150*185 | View Details |
| HNWC720D | 900 | 1000 | WEICHAI | 8M33D890E200 | T2 | 26.14 | 150*185 | View Details |
| HNWC800D | 1000 | 1100 | WEICHAI | 8M33D975E310 | T3 | 26.14 | 150*185 | View Details |
| HNWC900D | 1125 | 1237 | WEICHAI | 12M33D1108E200 | T2 | 39.2 | 150*185 | View Details |
| HNWC1000D | 1250 | 1375 | WEICHAI | 12M33D1210E200 | T2 | 39.2 | 150*185 | View Details |
 |
loading
| Availability: | |
|---|---|
| Quantity: | |
HN18D
HAONENG Power
Diesel Generator Set-Basic Parameters
Model: HN18D
Rated power: 22(KVA)
Output current: 32（A）
Weight: 920（KG）
Silent type size: 2100*900*1200
Output voltage: 400/230 (V)
Diesel Engine-Basic Parameters
Model: HN490D
Rated power: 27(KVA)
Emission standard: T2
Manufacturer: HAONENG
Bore: 90（mm）
Stroke: 100（mm）
Speed control mode: electronic speed control
Displacement: 2.544（L）
Fuel consumption rate: 200 (g/Kw.h)
Oil consumption rate: 0.3 (g/Kw.h)
Cooling method: Closed water circulation forced air-cooled
Speed: 1500 (RPM)
Thermostat adjustment temperature range: 82-93 (°C)
Exhaust temperature: 405/410 (°C)
Allowable back pressure: 10 (KPa)
Intake air resistance: 2.5 (KPa)
Fuel specification and grade: China 0# (light diesel oil)
Fuel consumption: ≤250（g/Kw.h）
Cylinder arrangement: L-type
Starting method: electric start
Controller-Basic Parameters
Brand: SmartGen/DSE
Display mode: LCD
Language type: support for the world's eight languages
Automatic function: automatic start, automatic stop
Motors - Basic Parameters
Model: HN-184E
Rated power: 22（KVA)
Standby power: 25（KVA)
Brand: HAONENG (standard)
Motor type: brushless three-phase AC synchronous generator
Voltage Regulation: AVR (Automatic Voltage Regulation)
Temperature rise: H°C
Overcurrent: 3～5le≥5S
Overload capacity: 3～5le≥5S
Short-circuit current: 3 times 2 seconds
Short-circuit capability: 3 times 2 seconds
Power factor: 0.8
Insulation/protection grade: H class/IP23
Wiring: three-phase four-wire, Y-type connection
Rated voltage: 400/230(V)
Winding material: pure copper
Cooling method: self-cooling
Excitation method: self-excitation
Telephone interference factor: THF<2, TIF<50
Attachment
Housings：21mm Plate Thickness
Sump：4mm Thick
Surface Treatment Process：Shot Peening Plus Plastic Spraying
Connecting chassis material: bending steel plate
Chassis strength: passed 500KG torsion test
Unit steel common base (including: unit composite vibration damping rubber mat)
Cooling water tank capacity: 8 Hours As Standard
Cooling water tank heat sink spacing: 0.80CM
Fuel tank material: 2MM high-quality cold-rolled steel plate
Silencer box: honeycomb double-layer industrial silencer
Vibration damping pads: bowl type or square type rubber vibration damping pads
Battery: Varta
